CHROX X96Q PRO+ Android 14.0 TV Box User Manual

1. Въведение

The CHROX X96Q PRO+ is an advanced Android 14.0 TV Box designed to transform your television into a smart entertainment hub. Featuring an H728 Quad-Core ARM Cortex-A55 processor and Mali G31 MP2 GPU, it delivers high-performance media playback, including 8K and 4K resolutions. This device supports dual-band Wi-Fi (2.4G/5.8GHz), Bluetooth 4.1, and offers various connectivity options for a comprehensive multimedia experience.

2. Съдържание на пакета

Моля, проверете дали всички изброени по-долу артикули са включени във вашия пакет:

• 1 x CHROX X96Q PRO+ TV Box
• 1 x Дистанционно управление
• 1 x HD кабел (HDMI)
• 1 x Захранващ адаптер (DC 5V/2A)
• 1 x Ръководство за потребителя

Image: Contents of the CHROX X96Q PRO+ TV Box package, including the TV box, remote control, HDMI cable, power adapter, and user manual.

3. Ръководство за настройка

3.1 Свързване на телевизионния приемник

1. Свързване с телевизор: Използвайте предоставения HDMI кабел, за да свържете HDMI порта на телевизионната кутия към наличен HDMI вход на вашия телевизор.
2. Захранване: Включете захранващия адаптер в DC 5V порта на телевизионната кутия, след което свържете адаптера към електрически контакт.
3. Мрежова връзка (по избор):
   • Ethernet: За кабелна връзка свържете Ethernet кабел от вашия рутер към LAN порта на телевизионната кутия.
   • Wi-Fi: For a wireless connection, you will configure Wi-Fi after initial power-on.
4. Свързване на периферни устройства (по избор): Insert USB devices such as a mouse, keyboard, or external storage into the available USB 2.0 or USB 3.0 ports.

Image: Diagram showing the various ports and dimensions of the CHROX X96Q PRO+ TV Box, including USB 2.0, USB 3.0, Ethernet, HD (HDMI), Audio, Optical, DC/5V, and Card slot.

3.2 Първоначално включване

After connecting all necessary cables, the TV Box should power on automatically. If not, press the power button on the device or the remote control. Select the correct HDMI input on your television to display the TV Box interface.

4. Инструкции за работа

4.1 Навигация в потребителския интерфейс

Use the provided remote control to navigate the Android 14.0 interface. The directional buttons allow you to move between icons and menus, the 'OK' button confirms selections, and the 'Back' button returns to the previous screen. A connected USB mouse or keyboard can also be used for easier navigation and text input.

4.2 Мрежова връзка

To access online content, connect your TV Box to the internet.

• Wi-Fi: Отидете на Настройки > Мрежа > Wi-Fi. Select your desired network from the list, enter the password if prompted, and connect. The device supports dual-band 2.4G and 5.8GHz Wi-Fi for stable and fast connections.
• Ethernet: If an Ethernet cable is connected, the device should automatically detect and connect to the wired network. Verify the connection status in Settings > Network > Ethernet.

Image: Illustration highlighting the Wi-Fi 6 technology of the CHROX X96Q PRO+ TV Box, indicating faster speed and lower latency compared to Wi-Fi 5.

4.3 Възпроизвеждане на медийни файлове

The CHROX X96Q PRO+ supports high-resolution video playback:

• 8K/4K Resolution: Enjoy ultra-high-definition content with support for up to 8Kx4K @60fps output.
• Декодиране на видео: Compatible with H.265 HEVC, H.264 AVC, and VP9 codecs for efficient and high-quality video streaming.
• HDR поддръжка: Experience enhanced color and contrast with HDR technology.

4.4 Многоекранно взаимодействие

Share content from your mobile devices to your TV screen using the built-in multi-screen features:

• Възпроизвеждане: За iOS устройства.
• DLNA: For compatible devices and media servers.
• Miracast: За устройства с Android.

Ensure your mobile device and the TV Box are connected to the same Wi-Fi network for these features to function.

Image: Depiction of multi-screen interaction, showing a smartphone and laptop casting content to a TV via the CHROX X96Q PRO+ TV Box using Airplay, DLNA, and Miracast.

4.5 3D Display

The TV Box supports 3D display, offering an immersive viewing experience with compatible 3D content and a 3D-enabled television.

Image: A person playing a 3D game on a TV, demonstrating the 3D display capability of the CHROX X96Q PRO+ TV Box.

4.6 Свързване на външни устройства

Expand your storage and connectivity options:

• USB портове: Connect USB flash drives, external hard drives (up to 1TB), game controllers, or other USB peripherals.
• Слот за Micro SD карта: Insert a Micro SD card (up to 64GB) to expand storage for apps and media.

5. Поддръжка

5.1 Актуализации на софтуера (OTA)

The TV Box supports Over-The-Air (OTA) updates. When connected to the internet, the device can automatically download and install the latest firmware updates to improve performance and add new features. It is recommended to keep your device updated for optimal functionality.

5.2 Почистване

To clean the device, use a soft, dry cloth. Avoid using liquid cleaners or abrasive materials, as they may damage the surface or internal components.

6. Отстраняване на проблеми

• Без захранване: Ensure the power adapter is securely connected to the TV Box and a working power outlet. Try a different outlet.
• Няма сигнал на телевизора: Verify the HDMI cable is properly connected to both the TV Box and the TV. Ensure your TV is set to the correct HDMI input source.
• Проблеми с Wi-Fi връзката: Check if your router is working correctly. Restart the TV Box and your router. Re-enter the Wi-Fi password in settings.
• Дистанционното управление не реагира: Проверете батериите в дистанционното управление и ги сменете, ако е необходимо. Уверете се, че няма препятствия между дистанционното и телевизионния приемник.
• Apps Not Working: Ensure the device has a stable internet connection. Try clearing the app's cache or reinstalling the app.

7. Спецификации

Image: Close-up of the CHROX X96Q PRO+ TV Box highlighting the Allwinner H728 CPU, Octa-core ARM Cortex A55, and Mali G57 GPU.

8. Гаранция и поддръжка

For any questions or issues regarding your CHROX X96Q PRO+ TV Box, please contact the seller, MYYGZQ. They are committed to resolving your problem within 24 hours. Please refer to your purchase documentation for specific warranty terms and contact details.
