Въведение
This manual provides detailed instructions for the assembly, operation, and maintenance of your VanAcc 70-inch Fireplace TV Stand with 36-inch Electric Fireplace. Please read all instructions carefully before assembly and use to ensure safe and proper functionality.
Информация за безопасност
Важни предпазни мерки за безопасност:
- Always secure the TV stand to the wall to prevent tip-over. Use appropriate wall anchoring hardware (not included).
- Внимавайте с острите ръбове по време на сглобяване и работа.
- Дръжте малките части далеч от деца, за да предотвратите опасност от задавяне.
- Ensure all electrical connections for the fireplace are properly installed and meet local electrical codes.
- Не претоварвайте електрическите контакти.
- The electric fireplace is CTL-certified and equipped with an automatic overheating cutoff system. Do not block air vents.
- Unplug the fireplace from the power outlet before cleaning or performing any maintenance.
Съдържание на пакета
Your VanAcc Fireplace TV Stand will be delivered in two separate packages (Box #1 and Box #2), which may arrive on different days. Please verify that all parts are intact and accounted for upon receipt of both boxes.
Image: Illustration showing two packages, Box A and Box B, for the TV stand and fireplace components.
Refer to the included assembly diagram for a complete list of parts and hardware.
Инструкции за сглобяване
Assembly typically requires two people and may take approximately 2-3 hours. A power drill can expedite the process. Follow the numbered steps in the provided assembly diagram carefully.
- Разопаковайте и идентифицирайте частите: Carefully unpack all components from both boxes. Lay them out on a clean, soft surface to prevent scratches. Identify each part using the provided parts list and diagrams.
- Сглобете основната рамка: Begin by connecting the main panels of the TV stand. Ensure all cam locks and dowels are securely fastened.
- Монтиране на регулируеми рафтове: Insert the shelf pins into the desired holes within the cabinet sections, then place the adjustable shelves on top.
- Прикрепете вратите на шкафовете: Mount the cabinet doors using the provided hinges. Adjust hinges as necessary to ensure doors are level and close properly.
- Монтирайте регулируеми крачета: Screw the adjustable table legs into the designated positions on the bottom of the TV stand. Adjust their height to ensure stability.
- Интегрирайте електрическата камина: Carefully slide the 36-inch electric fireplace into its designated opening in the center of the TV stand. Ensure it is flush and secure.
- Свържете LED светлини: Attach the LED light strip according to the diagram. Ensure the power cord for the LED lights is routed neatly and securely to prevent it from hanging.
- Окончателно поставяне и закрепване: Position the assembled TV stand in its desired location. Secure the stand to the wall using appropriate anti-tip hardware (not included) to prevent accidental tipping.
Image: Product dimensions and weight capacity diagram.
Image: Details of adjustable features including legs and internal shelving.
Инструкция за работа
Работа на електрическа камина
The electric fireplace can be controlled via the responsive remote control or the intuitive touchscreen interface located on the unit.
Image: Fireplace controls and features, including remote and touchscreen.
- Включване/изключване: Press the power button on the remote or touchscreen to turn the fireplace on or off.
- Цветове на пламъка: Select from 8 different flame colors with a fire gradient effect. Use the flame color button to cycle through options.
- Яркост на пламъка: Adjust the flame brightness across 5 levels using the brightness control button.
- Функция за отопление: The fireplace offers dual heating options (750W/1500W) with a maximum output of 4800 BTU. Press the heat button to activate and select the desired wattage. The temperature can be adjusted between 62-82°F.
- Таймер: Set a timer for 1-8 hours using the timer button for automatic shut-off.
- Защита от прегряване: The unit is equipped with an automatic overheating cutoff system for safety. If the unit overheats, it will shut down automatically. Unplug and allow it to cool for 15-20 minutes before restarting.
Изображение: Прamples of the 8 different flame colors.
Работа с LED светлини
The LED light strip under the TV stand features 12 adjustable colors.
Image: TV stand with blue LED lighting activated.
- Избор на цвят: Use the dedicated LED light control on the remote or touchscreen to cycle through the 12 available colors.
- Регулиране на яркостта: Adjust the brightness of the LED lights to your preference.
Изображение: Прamples of the 12 different LED light colors.
Поддръжка
- Почистване: Unplug the unit before cleaning. Use a soft, damp cloth to wipe down surfaces. Avoid abrasive cleaners or solvents that may damage the high-gloss finish.
- Прах: Regularly dust the unit to prevent accumulation, especially around the fireplace vents.
- Инспекция: Периодично проверявайте всички връзки и хардуер, за да се уверите, че са здрави и сигурни.
Отстраняване на неизправности
| проблем | Възможна причина | Решение |
|---|---|---|
| Камината не се включва. | Не е включен в контакта; захранването е изключено; предпазителят е задействан; защитата от прегряване е активирана. | Ensure unit is securely plugged into a working outlet. Check the main power switch. Reset the circuit breaker if tripped. If overheat protection activated, unplug and allow to cool for 15-20 minutes before restarting. |
| Няма топлинна мощност. | Heating function not activated; low wattage setting; air vents blocked. | Ensure heating function is turned on and set to desired wattage (750W/1500W). Check that air intake and exhaust vents are clear of obstructions. |
| LED светлините не работят или трептят. | Разхлабена връзка; проблем със захранването. | Check all LED light strip connections. Ensure the power adapter for the LED lights is securely plugged in. |
| Cabinet doors are not level. | Пантите изискват регулиране. | Регулирайте винтовете на пантите, за да подравните вратите. Вижте схемата за монтаж за подробности относно регулирането на пантите. |
| Устройството се усеща нестабилно. | Legs not properly adjusted; unit not secured to wall. | Ensure all adjustable legs are firmly on the ground and adjusted for even support. Secure the TV stand to the wall using anti-tip hardware. |
Спецификации
- марка: VanAcc
- Номер на модела: TV Stand70in
- материал: High Gloss Engineered Wood
- Размери на продукта: 70 x 15.8 x 24 инча (Д x Ш x В)
- Тегло на артикула: 117 паунда
- Размер на камината: 36 инча
- Maximum TV Size Supported: До 80 инча
- Максимален капацитет на тегло: 250 фунта
- Fireplace Heating Options: 750W/1500W
- Fireplace BTU Output: 4800 BTU
- Fireplace Temperature Control: 62-82°F
- Цветове на пламъка: 8 options with gradient effect
- Яркост на пламъка: 5 нива
- Цветове на LED светлината: 12 опции
- Сертификация за безопасност: CTL-certified electric fireplace with automatic overheating cutoff system.
Гаранция и поддръжка
For warranty information or technical support, please contact VanAcc customer service. Refer to your purchase documentation for specific contact details or visit the official VanAcc webсайт.
Онлайн ресурси: Visit the VanAcc Store on Amazon
